4 Port 30W PD & QC 3.0 USB Charger

SKU: 4 Port 30W PD & QC 3.0 USB Charger
  • Ultra-compact & ultra-light design
  • Charging up to 4 devices, with a maximum output of 30W
  • 1 Type C port – supports up to 20W fast charging with PD 3.0 (when used alone)
  • 3 USB-A ports – one of the ports supports up to 18W fast charging with QC 3.0 (when used alone)
  • With 4 protection systems and multi-national safety certificates

Product Features

Ultra-compact & Ultra-light Design

The 4 Port 30W PD & QC 3.0 USB Charger is in ultra-compact & ultra-light design. It only has 76.9 x 49.5 x 45.1 mm and weighted 68g.

With a maximum output of 30W

The USB Charger is equipped with 4 charging ports. With a total maximum output of 30W, it can maximize charging efficiency and speed in a portable size.

PD 3.0 & QC 3.0 fast charging

The 4 charging ports include : 1 Type C PD 3.0 port supports up to 20W fast charging when used alone; 1 USB-A QC 3.0 port supports up to 18W fast charging when used alone; and 2 USB-A ports support up to 10W charging when used alone. The Charger is able to charge 4 devices simultaneously, compatible with iPhone, iPad & most smartphones with fast charging functions.

With 4 protection systems & Multi-national safety certificates

The Charger is designed with 4 safety protection including over current protection, over voltage protection, over temperature protection and short circuit protection. In addition, the Charger has gained IEC62368 (H.K.), FCC (U.S.), CE (EU) and RoHS certificates. It is also supported with Global Product Liability Insurance.

For the output wattage

Please refer to this table.

  • Input : 100-240 V AC 50/60 Hz 0.5A (Max.)
  • Output:
    • Type C (PD 3.0) – 5Vdc/3A, 9Vdc/2.22A, 12Vdc/1.67A (Max. 20W)
    • USB-A 1 (QC 3.0) – 5Vdc/3A, 9Vdc/2A, 12Vdc/1.5A (Max. 18W)
    • USB-A 2 / USB-A 3 – Each 5Vdc/2A (Max. 10W)
    • Total 30W Max.
  • Over current protection, over voltage protection, short circuit protection and over temperature protection
  • Operating temperature:0°C – 40°C
  • Storage temperature:-20°C – 40°C
  • Product Dimensions:76.9 x 49.5 x 45.1 mm
  • Product Weight:68g
  • Material:PC Flame resistant material
  • Warranty:1-year limited warranty
